XB2-BA Metal Body Flush Push Button Switches (22mm) | ZAIN
The ZAIN XB2-BA Series 22mm Metal Body Push Button Switches provide standard manual control for electrical panels, machinery start/stop stations, motor starters, and automation circuits. Designed with a momentary spring-return action, the actuator returns to its normal state once released.
Constructed with a sturdy metal mounting collar and chrome-plated metal bezel that fastens into standard 22mm panel cutouts using rear fixing screws. Includes a detachable base contact block with captive screw clamp terminals for fast wiring connection.
Available Models:
• XB2-BA31 Green (1NO)
• XB2-BA42 Red (1NC)
• XB2-BA21 Black (1NO)
Technical Specifications
Brand: ZAIN
Country of Origin: China
Product Type: Flush Push Button Switch
Series: XB2-BA
Mounting Hole Diameter: 22mm
Bezel / Body Material: Chrome-Plated Metal
Action Type: Momentary (Spring Return)
Contact Ratings: Ui 600V, Ith 10A, AC-15 (240V 3A)
Terminal Type: Screw Clamp Terminals
Application: Industrial Control Panels, Motor Control Starters, Machine Operator Consoles, Distribution Boards, and Automation Stations
