A2 Type Brass Cable Gland (16L – 90L) | CABTEK | Made in India

Description

A2 Type Brass Cable Gland (16L – 90L) | CABTEK | Made in India

The CABTEK A2 Type Cable Gland is an industrial compression fitting engineered for unarmoured, flexible, and circular cables in indoor and outdoor installations. Precision-machined from high-grade CW614N brass, it secures the cable outer sheath while preventing dust and water jet ingress.

Equipped with an outer displacement seal delivering IP66 ingress protection and an operating temperature range of -60°C to +125°C. Suitable for power distribution boxes, control panels, switchgear, junction enclosures, and machinery connections.

Available Sizes:
• A2 16L
• A2 20S
• A2 20L
• A2 25L
• A2 32L
• A2 40L
• A2 50S
• A2 50L
• A2 63S
• A2 63L
• A2 75S
• A2 75L
• A2 90L

Technical Specifications

Brand: CABTEK

Origin: Made in India

Gland Type: A2 Type (Unarmoured Cable Gland)

Design Standards: BS 6121:Part-1:2005, EN 50262:1999, IEC 62444:2010

Material: Extruded Brass CW614N

Seal Material: LSOH Silicone Seal

Cable Type: Unarmoured / Flexible Cable

Ingress Protection: IP66

Operating Temperature: -60°C to +125°C

Thread Type: Standard Metric ISO

Available Sizes: A2 16L, A2 20S, A2 20L, A2 25L, A2 32L, A2 40L, A2 50S, A2 50L, A2 63S, A2 63L, A2 75S, A2 75L, A2 90L

Application: Control Panels, Terminal Enclosures, Switchgear, Industrial Automation, and Machinery
