XB2-EA Plastic Body Flush Push Button Switches (22mm) | ZAIN
The ZAIN XB2-EA Series 22mm Plastic Body Push Button Switches provide standard manual control for electrical panels, machinery start/stop stations, motor starters, and automation circuits. Designed with a momentary spring-return action, the actuator returns to its normal state once released.
Constructed with an all-plastic mounting collar and threaded retaining ring that fastens into standard 22mm panel cutouts. Includes a detachable base contact block with captive screw clamp terminals for wiring connection.
Available Models:
• XB2-EA31 Green (1NO)
• XB2-EA42 Red (1NC)
• XB2-EA21 Black (1NO)
Technical Specifications
Brand: ZAIN
Country of Origin: China
Product Type: Flush Push Button Switch
Series: XB2-EA
Mounting Hole Diameter: 22mm
Bezel / Body Material: Plastic / PVC
Action Type: Momentary (Spring Return)
Contact Ratings: Ui 600V, Ith 10A, AC-15 (240V 3A)
Terminal Type: Screw Clamp Terminals
Application: Industrial Control Panels, Motor Control Starters, Machine Operator Consoles, Distribution Boards, and Automation Stations
